MD_Parola.h File Reference

Main header file for the MD_Parola library. More...

#include <Arduino.h>
#include <MD_MAX72xx.h>

Include dependency graph for MD_Parola.h:

This graph shows which files directly or indirectly include this file:

Classes
class	MD_PZone
class	MD_Parola

Macros
#define	ENA_MISC   1
	Enable miscellaneous animations.
#define	ENA_WIPE   1
	Enable wipe type animations.
#define	ENA_SCAN   1
	Enable scanning animations.
#define	ENA_SCR_DIA   1
	Enable diagonal scrolling animation.
#define	ENA_OPNCLS   1
	Enable open and close scan effects.
#define	ENA_GROW   1
	Enable grow effects.
#define	ENA_SPRITE   1
	Enable sprite effects.
#define	ENA_GRAPHICS   1
	Enable graphics functionality.
#define	ARRAY_SIZE(x)   (sizeof(x)/sizeof(x[0]))
	Generic macro for obtaining number of elements of an array.
#define	MAX_ZONES   4
	Maximum number of zones allowed. Change to allow more or less zones but uses RAM even if not used.
#define	ZONE_START_COL(m)   (m*COL_SIZE)
	The first column of the first zone module.
#define	ZONE_END_COL(m)   (((m+1)*COL_SIZE)-1)
	The last column of the last zone module.

Enumerations
enum	textPosition_t { PA_LEFT, PA_CENTER, PA_RIGHT }
enum	textEffect_t {   PA_NO_EFFECT, PA_PRINT, PA_SCROLL_UP, PA_SCROLL_DOWN,   PA_SCROLL_LEFT, PA_SCROLL_RIGHT, PA_SPRITE, PA_SLICE,   PA_MESH, PA_FADE, PA_DISSOLVE, PA_BLINDS,   PA_RANDOM, PA_WIPE, PA_WIPE_CURSOR, PA_SCAN_HORIZ,   PA_SCAN_HORIZX, PA_SCAN_VERT, PA_SCAN_VERTX, PA_OPENING,   PA_OPENING_CURSOR, PA_CLOSING, PA_CLOSING_CURSOR, PA_SCROLL_UP_LEFT,   PA_SCROLL_UP_RIGHT, PA_SCROLL_DOWN_LEFT, PA_SCROLL_DOWN_RIGHT, PA_GROW_UP,   PA_GROW_DOWN }
enum	zoneEffect_t { PA_FLIP_UD, PA_FLIP_LR }

Detailed Description

Main header file for the MD_Parola library.

Enumeration Type Documentation

textEffect_t

enum textEffect_t

Text effects enumerated type specification.

Used to define the effects to be used for the entry and exit of text in the display area.

Enumerator
PA_NO_EFFECT	Used as a place filler, executes no operation.
PA_PRINT	Text just appears (printed)
PA_SCROLL_UP	Text scrolls up through the display.
PA_SCROLL_DOWN	Text scrolls down through the display.
PA_SCROLL_LEFT	Text scrolls right to left on the display.
PA_SCROLL_RIGHT	Text scrolls left to right on the display.
PA_SPRITE	Text enters and exits using user defined sprite.
PA_SLICE	Text enters and exits a slice (column) at a time from the right.
PA_MESH	Text enters and exits in columns moving in alternate direction (U/D)
PA_FADE	Text enters and exits by fading from/to 0 and intensity setting.
PA_DISSOLVE	Text dissolves from one display to another.
PA_BLINDS	Text is replaced behind vertical blinds.
PA_RANDOM	Text enters and exits as random dots.
PA_WIPE	Text appears/disappears one column at a time, looks like it is wiped on and off.
PA_WIPE_CURSOR	WIPE with a light bar ahead of the change.
PA_SCAN_HORIZ	Scan the LED column one at a time then appears/disappear at end.
PA_SCAN_HORIZX	Scan a blank column through the text one column at a time then appears/disappear at end.
PA_SCAN_VERT	Scan the LED row one at a time then appears/disappear at end.
PA_SCAN_VERTX	Scan a blank row through the text one row at a time then appears/disappear at end.
PA_OPENING	Appear and disappear from the center of the display, towards the ends.
PA_OPENING_CURSOR	OPENING with light bars ahead of the change.
PA_CLOSING	Appear and disappear from the ends of the display, towards the middle.
PA_CLOSING_CURSOR	CLOSING with light bars ahead of the change.
PA_SCROLL_UP_LEFT	Text moves in/out in a diagonal path up and left (North East)
PA_SCROLL_UP_RIGHT	Text moves in/out in a diagonal path up and right (North West)
PA_SCROLL_DOWN_LEFT	Text moves in/out in a diagonal path down and left (South East)
PA_SCROLL_DOWN_RIGHT	Text moves in/out in a diagonal path down and right (North West)
PA_GROW_UP	Text grows from the bottom up and shrinks from the top down.
PA_GROW_DOWN	Text grows from the top down and and shrinks from the bottom up.

textPosition_t

enum textPosition_t

Text alignment enumerated type specification.

Used to define the display text alignment and to specify direction for scrolling and animations. In the situation where LEFT AND RIGHT are the only sensible options (eg, text scrolling direction), CENTER will behave the same as LEFT.

Enumerator
PA_LEFT	The leftmost column for the first character will be on the left side of the display.
PA_CENTER	The text will be placed with equal number of blank display columns either side.
PA_RIGHT	The rightmost column of the last character will be on the right side of the display.

zoneEffect_t

enum zoneEffect_t

Zone effect enumerated type specification.

Used to define the effects to be used for text in the zone.

The FLIP_UD and FLIP_LR effects are specifically designed to allow rectangular shaped display modules (like Parola or Generic types) to be placed in an inverted position to allow all matrices to be tightly packed into a 2 line display. One of the lines must be flipped horizontally and vertically to remain legible in this configuration.

Enumerator
PA_FLIP_UD	Flip the zone Up to Down (effectively upside down). Works with all textEffect_t values.
PA_FLIP_LR	Flip the zone Left to Right (effectively mirrored). Does not work with textEffect_t types SLICE, SCROLL_LEFT, SCROLL_RIGHT.
